V-Tork Actuated PTFE Seat Lugged Butterfly Valves

V-Tork Actuated PTFE Seat Lugged Butterfly Valves are designed for precise flow control and reliability in industrial applications. Featuring a PTFE seat for enhanced chemical resistance and durability, these valves ensure optimal performance in harsh environments. The lugged design allows for easy installation and secure fitting between flanges. Actuation is smooth and efficient, offering reliable automation. Suitable for a wide range of fluids, V-Tork's actuators provide a dependable solution for your flow control needs.
Shop Help Me

Key Features

Key features and benefits of V-Tork Actuated PTFE Seat Lugged Butterfly Valves
1

Key Features

Lugged Butterfly Valves are commonly used in piping systems as a dead end service Valve or where regular/predicted disconnecting of the pipe on either side may need to be removed for maintenance and installation without disruption to both sides of the line.
2

Key Features

The V-Tork Pneumatic Rack & Pinion Actuators are available in both double-acting and spring-return configurations, offering versatility for a variety of applications. The double-acting models utilise air pressure for both opening and closing, providing enhanced control and force.
3

Key Features

The V-Tork Pneumatic Rack & Pinion Actuators are engineered to deliver high precision control in a compact form factor. Their streamlined design ensures they occupy minimal space while providing precise and reliable operation.

Why V-Tork

We have stock!

We understand the importance of minimising downtime and ensuring seamless operations. That's why we maintain a comprehensive stock of V-Tork actuators, ready for immediate dispatch.

Superior Durability and Reliability

V-Tork actuators are built to last, featuring a robust anodised aluminium housing that offers excellent resistance to corrosion and wear.

3D Step Files Available

These detailed 3D models facilitate seamless integration into your design and engineering processes. By providing precise geometrical representations, these files allow for accurate planning and simulation within CAD software.

Expert Customer Support

When you choose V-Tork actuators from Actuation Valve, you gain access to our exceptional customer support team. Our experts are dedicated to providing comprehensive assistance, from selecting the right product to troubleshooting and maintenance guidance.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Non Toxic FDA Approved PTFE

Wafer Pattern concentric design features a non-toxic PTFE internal seal which also partially covers the outer body of the valve for perfect sealing with counter flanges. Thus avoiding any possibility of cross-contamination and providing a butterfly valve that is extremely resistant to chemicals and solvents with complete insolubility to 300°C.

Engineered Shaft Design

A single piece shaft design brings high strength and stability with direct mount capabilities for actuation assemblies and ensures fluid is again isolated from both the shaft and the body of the butterfly valve. This also eliminates the need for a customised mounting assembly kit which can bring additional costs and time.

Choose Your Rubber

Material Applications Temperature
EPDM Water, Sea Water, Alcohols, Organic Salt Solutions, Mineral Acid Solutions, Mineral Based Alkalines -20°C +110°C
High Temperature EPDM Super Heated Water -20°C +130°C
NBR Buna Mineral & Vegetable Oils, Gas, Non Aromatic Hydrocarbons, Animal Fats, Vegetable Fats, Air -10°C +80°C
Hypalon Mineral Acid Solutions, Organic & In-Organic Acids, Oxidising Solutions -10°C +80°C
Viton Acids, Fats, Hydrocarbons, Vegetable & Mineral Oils, Fuels -5°C +180°C
Polyisoprene Water, Alcohols, Abrasive Substances (Call To Check), Ketones, -10°C +60°C
Silicone Low & High Temperature Resistance Applications -30°C +150°C
High Temp Silicone Super Heated Water -50°C +160°C
Epichlorohydrin Ozone Resistance, Hydrocarbons, Aromatic Oils -25°C +145°C

Take A Seat

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

V-Tork Actuator Brochures

  • Document
Brochure

VT New Series Pneumatic Actuator
  • Document
BROCHURE

VT Series Rack & Pinion Pneumatic Actuator
  • Document
BROCHURE

VTY Series Scotch Yoke Actuator
  • Document
BROCHURE

VTM Series Electric Actuator
  • Document
BROCHURE

VTS Series Scotch Yoke Actuator

More V-Tork Actuator Brochures

  • Document
Brochure

VTS Series Low Torque Scotch Yoke Actuator
  • Document
BROCHURE

VTMZ Series Multi-Turn Electric Actuator
  • Document
BROCHURE

VTMR Series Spring Return Electric Actuator
  • Document
BROCHURE

VT-3P Series Pneumatic Actuator

V-Tork Actuator Certificates

  • Document
Certificate

ISO9001
  • Document
CERTIFICATE

VT-CE
  • Document
CERTIFICATE

VTS-CE
  • Document
Certificate

VTORK - TUV
  • Document
CERTIFICATE

VTM IECEx & ATEX

More V-Tork Actuator Certificates

  • Document
Certificate

VT Series Double Acting SIL3 Certification
  • Document
CERTIFICATE

VT Series Spring Return SIL3 Certification
  • Document
CERTIFICATE

VTS Series Double Acting SIL 3 Certification
  • Document
Certificate

VTS Series Spring Return SIL 3 Certification

Valve Standards & Stuff
Body Material: GJS500-7 Ductile Iron Rilsan Coated
Disc Materials: PTFE, PFA, UHMWPE Stainless steel (CF-8M)
Shaft Materials: AISI 316, 17-4PH, Duplex
Face To Face: ISO 5752 Series 20, BS 5155 Wafer, DIN 3202 Part 3, Series K1
Pressure Testing: EN 12266-1, DIN 3230, BS 6755, ISO 5208
Connections: PN10/16 ANSI 150, ISO 705, DIN 2501, BS 4504, ANSI Class 150 ANSI B16.5
Sealing Testing: ISO 5208, API 598

Frequent Interrogation

The valve is suitable for almost all chemical applications. Send in an email of pick up the phone. One of our super tech guys will check it over for you.

Great. That would be in our actuated butterfly valve section! Have a look over there or get us on 0151 547 1221. We have what you need.

It certainly does. All of our PTFE butterfly valves come complete with a full set of operations and maintenance manuals from the manufacturer.

Yes we can. If you cant find what you are looking for on the website get in touch. We have valve switch boxes for all zoned and safe areas including LED visual indication.

Maybe. Give us a call to find out.

No. Why do people keep asking!? We are not the silly pink valve company.

Most definitely. We will require some more information. Drop us an email or get in touch on the blower.

Yes we can. Plane label or with a big bow. Send us a copy of your delivery note and we will fix it to the box. Job done.

We will need to talk to Big Tony. If he says you're good for the debt then everything is in order. You can apply for this on the product page or ask for Big Tony when you get in touch.
Collections are welcomed. Give us a call in advance and we can get you a time that suits.
