V-Tork Actuated Bronze Disc Lugged Butterfly Valves

The V-Tork Actuated Bronze Disc Lugged Butterfly Valves offer reliable flow control with enhanced durability, suitable for various industrial applications. Featuring a bronze disc and a lugged design, these valves ensure excellent resistance to corrosion and wear. The actuated mechanism provides precise operation, making them ideal for automated systems. With easy installation and low maintenance requirements, V-Tork butterfly valves deliver consistent performance, ensuring optimal efficiency and longevity in demanding environments.
Shop Help Me

Key Features

Key features and benefits of V-Tork Actuated Bronze Disc Lugged Butterfly Valves
1

Key Features

Actuation Valve & Control is a world-class manufacturer of actuated butterfly valves, with in house engineering and testing. We offer Direct Mounted Assemblies as well custom build bracket/shaft arrangements to ensure any application can be met.
2

Key Features

Our standard corrosive resistant Butterfly Valves are available in a wide range of sizes to suit all industry standards with 2" to 12" Butterfly Valves all available from stock in ANSI or DIN Flanged Connections.
3

Key Features

3D CAD and Step files readily available for new product line and system designs allowing integration within minutes. We also offer various mounting options including direct and bespoke box section kits so you can get the right fit for your project needs.

Why V-Tork

We have stock!

We understand the importance of minimising downtime and ensuring seamless operations. That's why we maintain a comprehensive stock of V-Tork actuators, ready for immediate dispatch.

Superior Durability and Reliability

V-Tork actuators are built to last, featuring a robust anodised aluminium housing that offers excellent resistance to corrosion and wear.

3D Step Files Available

These detailed 3D models facilitate seamless integration into your design and engineering processes. By providing precise geometrical representations, these files allow for accurate planning and simulation within CAD software.

Expert Customer Support

When you choose V-Tork actuators from Actuation Valve, you gain access to our exceptional customer support team. Our experts are dedicated to providing comprehensive assistance, from selecting the right product to troubleshooting and maintenance guidance.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Valve Rubber Stamps

  • PDF
CERTIFICATES & APPROVALS

Bureau Veritas
  • PDF
CERTIFICATES & APPROVALS

ABS
  • PDF
CERTIFICATES & APPROVALS

ATEX 2014/34/UE
  • PDF
CERTIFICATES & APPROVALS

ACS
  • PDF
CERTIFICATES & APPROVALS

PED 2014/68/UE
  • PDF
CERTIFICATES & APPROVALS

Lloyds ISO 9001

Choose Your Rubber

Material Applications Temperature
EPDM Water, Sea Water, Alcohols, Organic Salt Solutions, Mineral Acid Solutions, Mineral Based Alkalines -20°C +110°C
High Temperature EPDM Super Heated Water -20°C +130°C
NBR Buna Mineral & Vegetable Oils, Gas, Non Aromatic Hydrocarbons, Animal Fats, Vegetable Fats, Air -10°C +80°C
Hypalon Mineral Acid Solutions, Organic & In-Organic Acids, Oxidising Solutions -10°C +80°C
Viton Acids, Fats, Hydrocarbons, Vegetable & Mineral Oils, Fuels -5°C +180°C
Polyisoprene Water, Alcohols, Abrasive Substances (Call To Check), Ketones, -10°C +60°C
Silicone Low & High Temperature Resistance Applications -30°C +150°C
High Temp Silicone Super Heated Water -50°C +160°C
Epichlorohydrin Ozone Resistance, Hydrocarbons, Aromatic Oils -25°C +145°C

Take A Seat

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

V-Tork Actuator Brochures

  • Document
Brochure

VT New Series Pneumatic Actuator
  • Document
BROCHURE

VT Series Rack & Pinion Pneumatic Actuator
  • Document
BROCHURE

VTY Series Scotch Yoke Actuator
  • Document
BROCHURE

VTM Series Electric Actuator
  • Document
BROCHURE

VTS Series Scotch Yoke Actuator

More V-Tork Actuator Brochures

  • Document
Brochure

VTS Series Low Torque Scotch Yoke Actuator
  • Document
BROCHURE

VTMZ Series Multi-Turn Electric Actuator
  • Document
BROCHURE

VTMR Series Spring Return Electric Actuator
  • Document
BROCHURE

VT-3P Series Pneumatic Actuator

V-Tork Actuator Certificates

  • Document
Certificate

ISO9001
  • Document
CERTIFICATE

VT-CE
  • Document
CERTIFICATE

VTS-CE
  • Document
Certificate

VTORK - TUV
  • Document
CERTIFICATE

VTM IECEx & ATEX

More V-Tork Actuator Certificates

  • Document
Certificate

VT Series Double Acting SIL3 Certification
  • Document
CERTIFICATE

VT Series Spring Return SIL3 Certification
  • Document
CERTIFICATE

VTS Series Double Acting SIL 3 Certification
  • Document
Certificate

VTS Series Spring Return SIL 3 Certification

Valve Standards & Stuff
Body Material: B148 C9500 Aluminium Bronze
Seats Material: EPDM, NBR Buna, Hypalon, Viton, Silicone, High Temperature, Polyisoprene, Epichloridine
Design Standard: Concentric, Soft Seat
Face To Face: EN 558 Series 20, ISO 5752 Series 20, API 609 Table 1, BS 5155 Series 4
Pressure Testing: EN 12266-1, DIN 3230, BS 6755, ISO 5208
Connections: PN10/16 ANSI 150, ISO 7007, DIN 2501, BS 4504, ANSI Class 150 ANSI B16.5
Sealing Testing: ISO 5208, 100% Tight Shut Off, API 598

Frequent Interrogation

Yes, this Valve is suitable for sea water within the pressure and temperature limitations.

Great. The Namur standard interface is perfect for direct mounting a pilot solenoid valve. We can supply this actuated valve for you with or without a solenoid valve.
It certainly does. All of our actuated valves come complete with a full set of operations and maintenance manuals from both the valve and actuator manufacturers.

Yes we can. If you cant find what you are looking for on the website get in touch. We have valve switch boes for all zoned and safe areas including LED visual indication.

Maybe. Give us a call to find out.
No.
Most definitely. We will require some more information. Drop us an email or get in touch on the blower.
Yes we can. Plane label or with a big bow. Send us a copy of your delivery note and we will fix it to the box. Jop done.
We will need to talk to Big Tony. If he says you're good for the debt then everything is in order. You can apply for this on the product page or ask for Big Tony when you get in touch.
Collections are welcomed. Give us a call in advance and we can get you a time that suits.
