The SOCLA 405 Single Plate Check Valve ensures effective backflow prevention in clear and wastewater applications, including fire-fighting networks. Operating at pressures up to 16 bar and temperatures from -10°C to 70°C, it features a cast iron body with epoxy coating, NBR seals, and a low-head-loss design. The valve supports horizontal and vertical installations, complies with EN 1092-2 and PED 2014/68/UE standards, and offers optional features like a drain plug and plate lifting system.

 Technical Datasheet

The SOCLA 405L Single Plate Check Valves are designed to ensure efficient non-return functionality in various fluid handling systems. Constructed from durable materials, they feature a compact design for easy installation in tight spaces. These valves provide excellent sealing performance to prevent backflow, making them suitable for applications across water distribution, industry, and other demanding environments. With approvals for use in multiple systems, they offer a reliable and versatile solution for fluid control.

The SOCLA 627E Single Plate Check Valve ensures effective backflow prevention in clear liquid applications, including industrial processes and pumping systems. Operating at pressures up to 16 bar and temperatures from -10°C to 110°C, it features a stainless steel body and disc with EPDM seals. Designed for compact installation between flanges, it supports horizontal and vertical mounting and complies with EN 1092-2 and PED 2014/68/UE standards.

 Technical Datasheet

The SOCLA 627V Single Plate Check Valve ensures effective backflow prevention for clear liquids and hydrocarbons in industrial processes. Operating at pressures up to 16 bar and temperatures from -10°C to 150°C, it features a full stainless steel body, disc, and components with FKM seals. Designed for compact installation between flanges, it supports horizontal and vertical mounting and complies with EN 1092-2 and PED 2014/68/UE standards.

 Technical Datasheet

The SOCLA 635E Single Plate Check Valve ensures reliable backflow prevention in water supply, heating, and industrial processes. Operating at pressures up to 16 bar and temperatures from -10°C to 110°C, it features a cataphoresis-coated steel body and disc, stainless steel components, and an EPDM seal. Designed for compact installation between flanges, it supports horizontal and vertical mounting and complies with EN 1092-2 and PED 2014/68/UE standards.

 Technical Datasheet

The SOCLA 635V Single Plate Check Valve provides reliable backflow prevention for industrial processes and hydrocarbons. Operating at pressures up to 16 bar and temperatures ranging from -10°C to 150°C, it features a cataphoresis-coated steel body and disc, stainless steel components, and an FKM seal. Designed for compact installation between flanges, it supports horizontal or vertical mounting and complies with EN 1092-2 and PED 2014/68/UE standards, ensuring minimal head loss.

 Technical Datasheet

The SOCLA 696V Single Plate Check Valve ensures reliable backflow prevention for sea water, saline solutions, and aggressive fluids. Operating at pressures up to 16 bar and temperatures from -10°C to 150°C, it features an aluminium bronze body, disc, and components, with FKM seals. Designed for compact installation between flanges, it supports horizontal and vertical use and complies with EN 1092-2 and PED 2014/68/UE standards, ensuring efficient performance with minimal head loss.

 Technical Datasheet

The SOCLA 805 Plate Check Valve provides efficient backflow prevention for clear water and gas systems. Operating at pressures up to 25 bar and temperatures ranging from -10°C to 100°C (EPDM seals) or 80°C (NBR seals), it features a cast iron body with epoxy coating, aluminium bronze plates, and a stainless steel spring. Designed for compact installation between flanges, it supports horizontal and vertical positions and complies with EN 1092-2 and PED 2014/68/UE standards.

 Technical Datasheet

The SOCLA 815 Plate Check Valve ensures effective backflow prevention for clear water and gas applications. Operating at pressures up to 25 bar and temperatures ranging from -10°C to 100°C (EPDM seals) or 80°C (NBR seals), it features a cast iron body with epoxy coating, stainless steel or aluminium bronze plates, and a stainless steel spring. Designed for compact installation between flanges, it supports horizontal and vertical use and complies with EN 1092-2 and PED 2014/68/UE standards.

 Technical Datasheet

The SOCLA 825 Plate Check Valve ensures effective backflow prevention in systems handling clear liquids, gas, and hydrocarbons. Operating at pressures up to 25 bar and temperatures ranging from -10°C to 130°C, it features a stainless steel body, FKM seals, and a dual-plate design with a stainless steel spring. Designed for compact installation between flanges, it supports horizontal and vertical use and complies with EN 1092-2 and PED 2014/68/UE standards.

 Technical Datasheet

The SOCLA 895 Plate Check Valve provides reliable backflow prevention for clear water and gas applications. Operating at pressures up to 16 bar and temperatures from -10°C to 100°C, it features a cast iron body with epoxy coating, stainless steel plates and spring, and an EPDM seal. Designed for compact installation between flanges, it ensures low head loss and is suitable for horizontal and vertical positions. Compliant with EN 1092-2 and PED 2014/68/UE standards, it supports industrial and pumping systems.

 Technical Datasheet

The SOCLA 895V Plate Check Valve provides efficient backflow prevention for hydrocarbons, gas, and non-loaded liquids. Operating at pressures up to 16 bar and temperatures from -10°C to 100°C, it features a cast iron body with epoxy coating, stainless steel plates, an FKM seal, and a stainless steel spring. Designed for compact installation between flanges, it supports horizontal and vertical orientations. Compliant with EN 1092-2 and PED 2014/68/UE standards, it ensures minimal head loss.

 Technical Datasheet
