SAPAG Plate Check Valves

SAPAG Plate Check Valves, available in sizes DN15 to DN1000 (0.5" to 40"), are designed to handle pressures up to 160 bar and temperatures ranging from -196°C to 500°C. With end connections of PN10 and CI150, these valves are suitable for diverse industrial applications. Models include PrimeSwing, PrimeDisc S, PrimeDisc X, Prime2Disc, and ChemDisc. Though not carrying specific approvals, these valves ensure reliable performance in demanding conditions, making them a versatile choice for fluid control systems.
Shop Help Me

Key Features

Key features and benefits of the SAPAG Plate Check Valves
1

Key Features

The PrimeSwing | CSC Swing Check Valve offers efficient performance in a compact package. This valve is designed to provide reliable, unidirectional flow control with minimal pressure drop. Its compact design makes it suitable for installations where space is limited, without compromising on performance.
2

Key Features

The PrimeDisc S | CSD Standard Disc Check Valve is robust, economical, and reliable. This valve features a simple yet effective design that ensures dependable performance over a long service life. Its sturdy construction makes it capable of withstanding harsh operating conditions.
3

Key Features

The PrimeDisc X | DSF Xtreme Disc Check Valve is designed for use in high-pressure and high-temperature applications. Engineered to perform under the most demanding conditions, this valve can handle extreme pressures and temperatures without compromising on performance or safety.

Valve Standards & Stuff
Valve Size: DN15 to DN1000 (0.5" to 40")
Maximum Pressure: 160 bar
Temperature Range: -196°C to 500°C
End Connections: PN10 & CI150
Approvals: N/A
Models: PrimeSwing, PrimeDisc S, PrimeDisc X, Prime2Disc, & ChemDisc

Frequent Interrogation

A SAPAG check valve is a type of valve designed to allow fluid (liquid or gas) to flow through it in only one direction. These valves are commonly used in various industries to prevent backflow and ensure the efficient operation of piping systems.

SAPAG check valves operate by allowing fluid to flow in one direction while automatically preventing reverse flow. They typically consist of a disc or ball that moves to open or close the valve, responding to the pressure changes in the system.

SAPAG check valves are used in a wide range of applications, including water and wastewater treatment, chemical processing, oil and gas industries, and HVAC systems. They are essential for preventing backflow and ensuring the smooth operation of fluid systems.

SAPAG check valves are made from various materials, including stainless steel, cast iron, bronze, and plastic. The choice of material depends on the specific application and the type of fluid being handled.

Installing a SAPAG check valve involves ensuring the valve is correctly oriented with the flow direction marked on the valve body. Proper alignment, securing the valve with appropriate fittings, and checking for leaks after installation are crucial steps.

Benefits of SAPAG check valves include preventing backflow, protecting pumps and compressors from damage, maintaining pressure in the system, and improving overall system efficiency. They are also known for their durability and reliability.

Yes, SAPAG check valves are designed to handle high-pressure applications. They are built to withstand significant pressure differentials and are commonly used in industrial processes requiring robust performance.

Need More Dimensions?

No time for fancy software or your tekkers are just pretty substandard? We offer a full technical drawing service for our actuated valves. The Artists are ready to draw. Tell us what you need.

Technical Data

  • Document
Technical Sheet

SAPAG-VALVES-0041-ENG-2302
Request more information or Advice

Please feel free to request information and advice using the form below or call us on 0151 547 1221
