COAX VSV-M / VSV-F DR 3/2 Way Externally Controlled Coaxial Valves

The COAX VSV-M / VSV-F DR 3/2-way externally controlled coaxial valves are designed for precise fluid control across a range of pressures (PN 0-40 bar) and orifice sizes (DN 40-150). Constructed with pressure-balanced designs, spring returns, and switching overlaps, these valves suit applications involving gaseous, liquid, highly viscous, or contaminated media. Available in aluminium, galvanised, nickel-plated, and stainless steel bodies with NBR, PTFE, FPM, CR, EPDM, or specialised seals, they operate on DC 24V or AC 230V with threaded or flanged ports.

Key Features

Key features and benefits of the COAX VSV-M / VSV-F DR 3/2 Way Externally Controlled Coaxial Valves
1

Key Features

The COAX VSV-M / VSV-F DR valves are built to handle a wide range of media, including gaseous, liquid, highly viscous, and contaminated substances, making them ideal for diverse industrial applications where varied fluid types are involved.
2

Key Features

Available in aluminium, galvanised, nickel-plated, and stainless steel, these valves offer enhanced durability and corrosion resistance for long-lasting performance in demanding environments. The choice of NBR, PTFE, FPM, CR, EPDM, and specialised seals ensures adaptability to different operational requirements.
3

Key Features

Featuring a pressure-balanced design with spring return and switching overlap, these 3/2-way valves deliver precise control with reliable operation, supported by DC 24V or AC 230V actuation. This enables smooth, responsive transitions between flow paths for optimised system performance.

Valve Specifications

Valve Type: 3/2-way valve
Operating Method: Externally Controlled
Orifice Size: DN 40 - 150
Pressure Range: PN 0 - 40 bar
Port Type: Threaded / Flanged
Valve Design: Pressure Balanced, with Spring Return, Switching Overlap
Body Material: Aluminium, & Galvanised / Nickel Plated / & Stainless Steel
Seal Material: NBR, PTFE, FPM, CR, EPDM, Special Materials
Media: Gaseous, Liquid, Highly Viscous, Contaminated
Nominal Voltage: DC 24 V/AC 230 V

Frequently Asked Questions

A 3/2-way externally controlled coaxial valve is a type of valve with three ports and two switching positions, operated externally through pneumatic or hydraulic means, commonly used for controlled flow in industrial applications.

These valves are suitable for gaseous, liquid, highly viscous, and contaminated media, allowing flexible use across diverse industries with various fluid types.

This range operates effectively within a pressure range of PN 0 to 40 bar, making it versatile for low to high-pressure applications.

These valves come in orifice sizes ranging from DN 40 to DN 150, catering to different flow rate needs in industrial systems.

The valve bodies are available in aluminium, galvanised, nickel-plated, and stainless steel, offering durability and corrosion resistance in various operating environments.

Seal materials include NBR, PTFE, FPM, CR, EPDM, and specialised materials, providing options for compatibility with different media types and temperatures.

These valves are available with both threaded and flanged ports, allowing easy integration into existing piping and system designs.

These valves are externally controlled and can be actuated through a connected 5/2-way valve or existing valve terminal, facilitating remote operation.

The pressure-balanced design with a spring return and switching overlap ensures reliable, precise control over fluid flow, enhancing operational performance.

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Curabitur scelerisque tincidunt egestas. Donec tempor, lorem eu aliquet imperdiet, nisi tellus imperdiet erat, et ullamcorper nibh diam at orci. Integer placerat arcu pretium, condimentum ante et.

Yes, these valves are built to handle contaminated media effectively, making them suitable for environments with challenging fluid conditions.
