COAX V2 Special Valves

The COAX V2 Special Valves are 2/2-way, externally controlled valves with an orifice size ranging from DN15 to DN100, capable of handling pressures from PN 0 to 64 bar. Designed with a spring return mechanism, these flanged valves are built with nickel-plated steel or stainless steel bodies, using FPM or graphite seals. Ideal for gaseous media, they excel in demanding applications such as hot gas filtration and filter cleaning within coal gasification processes in power stations.
Shop Help Me

Key Features

Key features and benfits of Coaxial Special Valves Type V2.
1

Key Features

These valves are engineered to open and close swiftly, generating pressure surges essential for effective filter cleaning in coal gasification processes.
2

Key Features

Equipped with metal bellows, the valves ensure a hermetic seal to the external environment, preventing leakage and maintaining system integrity.
3

Key Features

Constructed with wear-resistant valve seats, the V2 valves can handle media temperatures up to 400°C, making them suitable for hot gas filtration applications.

Valve Specifications
Valve Type: 2/2 - Way Valve
Operating Method: Externally Controlled
Orifice Size: DN15 - 100
Pressure Range: PN 0 - 64 bar
Port Type: Flanged
Valve Design: Externally controlled with spring return
Body Material: Nickel Plated Steel, Stainless Steel
Seal Material: FPM, Graphite
Media: Gaseous
Special Applications: Hot Gas Filtration / Filter Cleaning of Coal Gasification in Coal Power Stations

Documents & Drawings

  • Document
DATASHEET

Type V2
  • Document
MANUAL

Operating Manual

Frequently Asked Questions

COAX V2 Special Valves are primarily used in hot gas filtration and filter cleaning during coal gasification processes in coal-fired power stations.

These valves operate within a pressure range of 0 to 64 bar.

The valves are available with orifice sizes ranging from DN15 to DN80.

The valve bodies are made from nickel-plated steel or stainless steel, with seals crafted from FPM or graphite.

Depending on the nominal width, these valves achieve switching times between 50 and 100 milliseconds.

They can handle media temperatures up to 400°C.

Yes, these valves are designed specifically for gaseous media applications.

They are pneumatically actuated and controlled via a direct-mounted or external 5/2-way pilot valve.

Yes, they feature a hermetic seal to the outside, ensuring no leakage.

These valves come with flanged connections.

The weight varies by size: DN15 to DN50 valves weigh approximately 23 kg, while DN65 to DN80 valves weigh around 130.5 kg.
