COAX SPB Pressure Control Valves - Pressure Limitation

The COAX SPB Pressure Limitation Valve, a proportional, externally controlled valve, offers versatile control with orifice sizes from DN 8 to DN 65, supporting pressure ranges up to PN 200 bar. Available with threaded or flanged ports, this valve comes in galvanised steel or brass with options for NBR, PTFE, or FPM seals, handling liquid, viscous, and contaminated media. Designed for DC 24 V systems, it’s available with or without spring return, ensuring adaptable, reliable pressure management across applications.

Key Features

Key features and benefits of the COAX SPB Pressure Control Valves - Pressure Limitation
1

Key Features

This valve allows precise pressure regulation through external control signals, enabling seamless integration into automated systems for accurate pressure management.
2

Key Features

Engineered to handle a wide range of media—including liquids, highly viscous substances, and contaminated fluids—the SPB valve ensures reliable performance across diverse industrial applications.
3

Key Features

Available in various configurations, the valve offers orifice sizes from DN 8 to DN 65, pressure ranges up to PN 200 bar, and choices between threaded or flanged ports.

Valve Specifications

Valve Type: Pressure Limitation Valve
Operating Method: Proportional Externally Controlled
Orifice Size: DN 8 - 65
Pressure Range: PN 0 - 200 bar
Port Type: Threaded / Flanged
Valve Design: Externally Controlled, with / without Spring Return
Body Material: Brass, Galvanised Steel
Seal Material: NBR, PTFE, FPM, special materials
Media: Liquid, Highly Viscous, Contaminated
Nominal Voltage: DC 24 V

Frequently Asked Questions

The COAX SPB valve operates within a pressure range of 0 to 200 bar, accommodating various industrial applications.

This valve is suitable for liquids, highly viscous substances, and contaminated media, ensuring versatility across different processes.

The valve offers orifice sizes ranging from DN 8 to DN 65, allowing selection based on specific flow requirements.

The valve body is constructed from brass or galvanised steel, with seals made from NBR, PTFE, FPM, or special materials, ensuring durability and compatibility with various media.

Yes, the valve is designed to handle contaminated media effectively, making it ideal for challenging industrial environments.

The valve is available with threaded or flanged port connections, providing flexibility for integration into different piping systems.

Yes, the valve features proportional external control, allowing precise pressure regulation through external signals.

The valve operates at a nominal voltage of DC 24 V, suitable for standard industrial power supplies.

Yes, the valve is available with or without a spring return mechanism, enabling selection based on specific operational needs.

Sealing options include NBR, PTFE, FPM, and special materials, ensuring compatibility with various media and operating conditions.

Yes, the valve is designed to manage highly viscous media, maintaining reliable performance across diverse applications.
