COAX RSV Lateral Valves

The COAX RSV Lateral Valve is a 2/2-way, direct-actuated valve suitable for managing gaseous and liquid media, supporting both normally closed (NC) and normally open (NO) positions. Featuring a pressure-balanced, spring-return design, it accommodates orifice sizes from DN 15 to DN 50 and operates within a pressure range of 0 to 10 bar. Available in brass or nickel-plated brass with NBR and FPM seals, this valve is compatible with DC 24 V or AC 230 V, making it ideal for systems requiring reliable switching between open and close positions.

Key Features

Key features and benefits of the COAX RSV Lateral Valves
1

Key Features

Designed to handle both gaseous and liquid media, the valve is suitable for a wide range of industrial applications.
2

Key Features

The valve's pressure-balanced construction ensures consistent performance across its operating pressure range of 0 to 10 bar, enhancing reliability in various conditions.
3

Key Features

With options for normally closed (NC) and normally open (NO) positions, the valve provides adaptability to different system requirements, facilitating seamless integration into diverse setups.

Valve Specifications

Valve Type: 2/2-way valve
Operating Method: Direct Actuated
Orifice Size: DN 15 - 50
Pressure Range: PN 0 - 10 bar
Port Type: Threaded
Valve Design: Pressure Balanced, with Spring Return
Body Material: Brass, Nickel Plated Brass
Seal Material: NBR, FPM
Media: Gaseous, Liquid
Nominal Voltage: DC 24 V / AC 230 V

Frequently Asked Questions

The COAX RSV Lateral Valve is a 2/2-way, direct-actuated valve designed for controlling the flow of gaseous and liquid media in various industrial applications.

The valve is available in orifice sizes ranging from DN 12 to DN 50, accommodating different flow requirements.

It operates within a pressure range of 0 to 10 bar, making it suitable for low to medium-pressure applications.

The valve body is constructed from brass or nickel-plated brass, with seals made from NBR or FPM, ensuring durability and compatibility with various media.

Yes, the valve is designed to handle both gaseous and liquid media, providing versatility across different applications.

The valve is compatible with DC 24 V and AC 230 V power supplies, offering flexibility in integration with various electrical systems.

Yes, the valve is available in both notmally closed and normally open configurations, allowing for adaptability to different system requirements.

The valve features threaded port connections, facilitating straightforward installation and maintenance.

Yes, the valve has a pressure-balanced design with a spring return mechanism, ensuring consistent performance across its operating pressure range.

The valve is widely used in industries such as packaging, glass, metal, and furniture, particularly in applications involving lifting tools like suction cups.

Yes, due to its design without dynamic seals, the valve is well-suited for use in dusty environments, such as vacuum furnaces.
