COAX PCD / PCD-H High Pressure Lateral Valves

The COAX PCD / PCD-H High Pressure Lateral Valve is a 2/2-way, externally controlled valve, suited for applications requiring high-pressure handling up to 500 bar. Available with orifice sizes from DN 10 to DN 15, this pressure-balanced, spring-return valve features a threaded port type and is constructed in brass or stainless steel. Compatible with gaseous and liquid media, it offers sealing options including NBR, PTFE, FPM, CR, and EPDM. Operable at DC 24 V or AC 230 V, the PCD / PCD-H ensures dependable performance in demanding environments.

Key Features

Key features and benefits of the COAX PCD / PCD-H High Pressure Lateral Valves
1

Key Features

These valves are engineered to handle pressures up to 500 bar, making them suitable for demanding applications requiring reliable performance under extreme conditions.
2

Key Features

Designed to manage both gaseous and liquid media, the PCD / PCD-H valves provide flexibility across various industrial processes, ensuring efficient operation regardless of the media type.
3

Key Features

Constructed from high-quality brass or stainless steel, these valves offer enhanced durability and corrosion resistance, ensuring longevity and consistent performance in challenging environments.

Valve Specifications

Valve Type: 2/2-way valve
Operating Method: Externally Controlled
Orifice Size: DN 10 - 15
Pressure Range: PN 0 - 500 bar
Port Type: Threaded
Valve Design: Pressure Balanced, with Spring Return
Body Material: Brass, Stainless Steel
Seal Material: NBR, PTFE, FPM, CR, EPDM
Media: Gaseous, Liquid
Nominal Voltage: DC 24 V / AC 230 V

Frequently Asked Questions

These valves are ideal for high-pressure systems in industries such as gas filling stations, test benches, compressor and hydraulic systems, and washing machines, handling pressures up to 500 bar.

The PCD / PCD-H valves are designed to operate at pressures up to 500 bar, ensuring reliable performance in high-pressure applications.

These valves come with orifice sizes ranging from DN 10 to DN 15, accommodating various flow requirements.

The valves are constructed from brass or stainless steel, offering durability and corrosion resistance for extended service life.

Sealing options include NBR, PTFE, FPM, CR, and EPDM, allowing compatibility with a wide range of media and operating conditions.

Yes, these valves are designed to handle both gaseous and liquid media, providing versatility across different industrial applications.

The valves can operate with nominal voltages of DC 24 V or AC 230 V, catering to various electrical system requirements.

These valves are externally controlled, allowing for precise operation in complex systems.

The valves feature threaded port connections, facilitating straightforward integration into existing piping systems.

Yes, they are designed with a pressure-balanced, spring-return mechanism, ensuring reliable closure after actuation.

The Kv value varies depending on the specific model and orifice size, with values up to 3.5 m³/h for certain models.
