COAX PCD Cartridge Valves

The COAX PCD Cartridge Valves are 2/2-way, externally controlled units available with orifice sizes DN 10-15 and a pressure range of PN 0-100 bar. Designed with a spring return and threaded ports, they suit gaseous, liquid, viscous, and contaminated media. Made from aluminium, brass, and stainless steel, with sealing options including PU, NBR, and PTFE, these valves offer versatile application. The 24V DC or 230V AC cartridge, secured by three screws, enables quick replacement within piping systems.

Key Features

Key features and benefits of the COAX PCD Cartridge Valves
1

Key Features

The COAX PCD Cartridge Valves are suitable for a wide range of media, including gaseous, liquid, highly viscous, and contaminated substances. This versatility makes them ideal for varied industrial applications, as they reliably handle challenging media without compromising performance.
2

Key Features

The valve cartridge attaches to the body using three screws, enabling rapid replacement without extensive downtime. This design simplifies maintenance, allowing operators to replace the cartridge within minutes, minimising disruption in high-demand environments.
3

Key Features

Constructed with body materials like aluminium, brass, and stainless steel and seals available in materials such as PU, NBR, PTFE, and more, these valves deliver durability and compatibility with diverse operational requirements and media, ensuring a longer service life.

Valve Specifications

Valve Type: 2/2-way valve
Operating Method: Externally Controlled
Orifice Size: DN 10 - 15
Pressure Range: PN 0 - 100 bar
Port Type: Threaded
Valve Design: Externally Controlled, with Spring Return
Body Material: Aluminium, Brass, & Stainless Steel
Seal Material: PU, NBR, PTFE, PE, FPM, EPDM, special materials
Media: Gaseous, Liquid, Highly Viscous, Contaminated
Nominal Voltage: DC 24 V / AC 230 V

Frequently Asked Questions

COAX PCD Cartridge Valves are 2/2-way, externally controlled valves designed for various industrial applications, handling media such as gases, liquids, and highly viscous substances.

These valves are available with orifice sizes ranging from DN 10 to DN 15, accommodating different flow requirements.

They operate effectively within a pressure range of PN 0 to 100 bar, making them suitable for both low and high-pressure systems.

The valve bodies are constructed from aluminium, brass, or stainless steel, with seals made from materials like PU, NBR, PTFE, PE, FPM, EPDM, and other special materials.

These valves are designed to handle gaseous, liquid, highly viscous, and contaminated media, providing versatility across various industrial processes.

They feature threaded ports, facilitating easy integration into existing piping systems.

These valves are externally controlled and come with a spring return mechanism, ensuring reliable operation.

They are compatible with DC 24 V and AC 230 V power supplies, offering flexibility in various electrical environments.

The valve cartridge is attached to the body with three screws, allowing for quick replacement within minutes without the need to remove the entire valve from the piping system.

These valves are used in industries such as chemical processing, oil and gas, and manufacturing, where reliable control of various media is essential.

They can perform up to 700 switching cycles per minute, with opening and closing times ranging from 30 to 3000 milliseconds, depending on the specific model and application.
