Biffi Morin B/C Low Pressure Actuators

The Biffi Morin B/C Low Pressure Actuators feature ductile iron housing with stainless steel (B Series) or carbon steel (C Series) cylinders, providing long-lasting, cost-effective performance. With both spring-return and double-acting options, these actuators deliver up to 1,400,000 lb·in of quarter-turn torque. Key components like high-strength alloy shafts and PTFE bushings reduce maintenance and enhance efficiency, making them ideal for industries such as chemical processing, power, oil and gas, and more. Rated for temperatures from -20°F to 210°F, they offer reliable performance in demanding environments.
Shop Help Me

Key Features

Key features and benefits of Biffi Morin B/C Low Pressure Actuators
1

Key Features

The Biffi Morin B/C Low Pressure Actuators are equipped with a ductile iron housing, piston, and end caps, providing a long lifespan and durable operation. This construction ensures the actuator remains cost-effective over time, offering reliable performance even in challenging conditions.
2

Key Features

The output shaft is made from high-strength alloy steel or 17-4PH stainless steel, which allows it to transmit torque efficiently without the risk of fatigue. This feature is essential for maintaining consistent performance under continuous use.
3

Key Features

The actuators utilise sintered bronze or PTFE composite output shaft bushings. These materials help to eliminate side loading on the valve stem, maximising the performance of the stem packing and ensuring smoother operation.

Actuator Specifications
Supply Pressure: 3 to 11 Barg
Supply Medium: Air or any Gas Compatible with Materials of Construction
Temperature Standard Range: -29°C to 99°C
Temperature Optional Range: -54°C to 149°C
Angular Rotation: 90 Degrees
Mounting Pattern: ISO 5211
Protection: IP66
Certification: SIL3 Capable
Applications: Chemical Process, Food & Beverage, Pharmaceutical, Power, Oil & Gas, & More
Actuator Design: Scotch Yoke

Technical Data Sheets

  • Document
DATASHEET

Biffi Morin B and C Series Actuators
  • Document
DATASHEET

Morin B WH-S WH Water Service Actuators Metrics
  • Document
DATASHEET

Biffi Morin Manual Override Options

Frequently Asked Questions

Biffi manufactures electric, pneumatic, hydraulic, and electro-hydraulic actuators for various industrial applications.

Biffi provides solutions for the oil & gas, power, water & wastewater, and industrial processing sectors.

Electric actuators automate valves, offering precise control for quarter-turn or multi-turn valve operations in industrial settings.

Biffi's low-pressure actuators are pneumatic solutions designed for rack-and-pinion, scotch yoke, and linear valve automation.

Biffi's high-pressure actuators provide robust control for small to large valves under very high-pressure conditions.

Electric actuators use electrical power, while pneumatic actuators rely on compressed air for valve automation.

Biffi actuators are designed for heavy-duty industrial use, featuring robust materials and advanced technology for longevity and reliability.

Yes, Biffi offers tailored solutions to meet the unique requirements of different industrial processes.

Electro-hydraulic actuators combine electric control with hydraulic power for reliable valve automation, even in power loss scenarios.

Biffi's compact actuators are designed for space-constrained environments, providing efficient quarter-turn valve control.

Biffi offers advanced control systems for monitoring and diagnostics of individual actuators and centralized control of multiple devices.

Biffi actuators meet international certifications such as ATEX, IECEx, and SIL, ensuring compliance with industry standards for safety, performance, and reliability in hazardous and critical environments.
