Bettis RPE-Series Pneumatic Rack and Pinion Actuator

The Bettis RPE-Series, a rack & pinion actuator, offers 12 sizes for quarter-turn valve applications, featuring a durable design with corrosion-resistant aluminum pinion and stainless steel fasteners for longevity. It's engineered for low maintenance, with precise dual stroke adjustment, and adheres to VDI/VDE 3845 standards for easy integration, ensuring a reliable solution for process plant environments.
Shop Help Me

Key Features

Key features and benefits of the Bettis RPE-Series Pneumatic Rack and Pinion Actuator
1

Key Features

The Bettis RPE-Series actuator is engineered with a special high corrosion-resistant aluminium pinion and stainless steel fasteners, along with a polyurethane powder-coated body, ensuring durability and a long service life in harsh environmental conditions.
2

Key Features

It offers precision dual stroke adjustment for accurate and intuitive end-of-stroke adjustment for both open and closed valve positions, enhancing operational efficiency and reliability.
3

Key Features

The actuator supports dual ISO 5211 mounting patterns for low-profile direct mounting to valves and features a one-piece, blow-out proof, pressure-balanced pinion allowing safe in-field reconfiguration from Fail-Close to Fail-Open, providing flexibility and safety in application.

Immense Stocks

Powerful Specifications
Supply Media: Pneumatic
Supply Pressure Range: Pneumatic Rack and Pinion Actuator
Actuation: Double-acting, Spring-return, Quarter-turn
Certifications: ROHS3, REACH, ATEX, PED and Machinery Directives, SIL3, IP66/67
Control Type: On/Off, Positioning, Modulating, ESD
Valve Type: Ball, Butterfly, Plug, Triple Offset Valves, Other Quarter-Turn Devices
Operating Temperature: Standard -20°C to +80°C (-4°F to +176°F). Optional high and low temperature options
Torque/Thrust: 12 sizes: 12 to 4100 Nm (106 to 36,474 lbf.in)
Operating Pressure: up to 8.3 bar / 120 psi

Actuated Valve Testing & Calibration

All actuated valve assemblies are fully tested and calibrated in house prior to packing and shipping from our expert team of technical engineers. This means that when they arrive at site, you're immediately ready to install and get your production back up and running.

Certificates and Datasheets

  • PDF
Certificates and Datasheets

Bettis Range
  • PDF
Certificates and Datasheets

RPE Series Brochure
  • PDF
Certificates and Datasheets

RPE Catalog
  • Document
Certificates and Datasheets

RPE Series ATEX Certificate
Request more information or Advice

Please feel free to request information and advice using the form below or call us on 0151 547 1221
