The ASCO™ Series 353 Pulse Solenoid Valves are designed for reverse-jet dust collector systems, offering fast pulsing and high flow rates for efficient filter cleaning. With reduced air consumption, the valves help users achieve energy savings. They feature a long life, extended temperature range, and a patented Quick Mount Clamp connection for quicker installation. Available in various sizes and voltages, the Series 353 operates effectively in hazardous and outdoor environments. Explore potential air savings with our calculator.

Key features and benefits of ASCO™ Series 353 Pulse Solenoid Valves

Key Features

The Series 353 delivers extremely fast response times, making it ideal for reverse-jet dust collectors. This fast pulsing ensures effective and thorough filter cleaning, which extends filter life and improves overall system efficiency.

Key Features

By using less air than traditional valves, the Series 353 significantly reduces operating costs. This energy-efficient design minimises compressed air usage, helping users lower energy expenses and reduce their environmental footprint.

Key Features

The patented Quick Mount Clamp connection allows for faster and simpler installation compared to traditional threaded connections. This not only saves time during setup but also reduces maintenance efforts, making it a practical choice for various industrial applications.


Valve Actuation:	Air Pilot, Air Operated
Body Material:	Aluminium
Media:	Air
Pipe / Port Size:	3/4 "; 1 "; 1 1/4 "; 1 1/2 "; 2 "; 2 1/2 "; 3 "
Port Type:	NPTF, G-Thread, Quick Mount Clamp Connection
Function:	2 way - 2/2 Normally Closed
Flow:	From 10 to 20 Cv, from 35 to 57 Cv, from 60 to 140 Cv
Voltage:	24 AC to 480 AC
Operating Environment:	Hazardous, Indoor, Outdoor
Temperature Range:	-40°C to 140°C

Document

ARTICLE

Document

ARTICLE

Document

DATASHEET

The ASCO™ Series 353 Pulse Solenoid Valve is primarily used in reverse-jet dust collector systems, delivering fast pulsing to optimise filter cleaning and system efficiency.

The ASCO™ Series 353 uses significantly less air during operation, leading to reduced energy consumption and cost savings over time.

The patented Quick Mount Clamp allows for faster and easier installation compared to traditional threaded connections, reducing setup time and simplifying maintenance.

The ASCO™ Series 353 is suitable for hazardous, indoor, and outdoor environments, making it versatile for various industrial applications.

This valve operates in a wide temperature range, from -40°F to 284°F, making it suitable for diverse industrial conditions.

The valve is available in various port sizes, ranging from 3/4" to 3", ensuring flexibility for different system requirements.

The valve is designed to handle air as the operating media, making it ideal for dust collector applications.

Yes, the ASCO™ Series 353 meets multiple industry standards and regulations, including UL, CSA, and ATEX, making it safe for use in hazardous zones.

The flow capacity ranges from 10 Cv to 140 Cv, depending on the valve size, allowing for customisation based on system needs.

The valve supports a wide range of voltages, including 24V DC, 110 AC, 230 AC, and more, providing compatibility with various electrical systems.

Yes, the valve is certified for use in hazardous locations, including ATEX Zones 1–21 and Class I Div 1, ensuring safe operation in dangerous environments.
