ARI-PREMIO Plus 2G Electric Thrust Actuator

The ARI-PREMIO Plus 2G Electric Thrust Actuator delivers reliable performance in two force ranges: 2.2 to 5 kN and 12 to 25 kN, with operating speeds from 0.20 mm/s to 1 mm/s. It offers a maximum travel distance of 50-65 mm, powered by a BLDC motor with a supply voltage of 24 V AC/DC. Power consumption varies by model, up to 137 VA, and it is rated IP65 for protection. Suitable for ambient temperatures from -20°C to 70°C, it weighs between 5.4 and 11 kg, ensuring versatile application.
Shop Help Me

Key Features

Key features and benefits of the ARI-PREMIO Plus 2G Electric Thrust Actuator
1

Key Features

The ARI-PREMIO Plus 2G provides force options ranging from 2.2 kN to 25 kN, allowing for flexibility across various applications requiring precise and powerful linear motion.
2

Key Features

With power consumption as low as 28 VA and a maximum of 137 VA, this actuator operates efficiently without compromising on performance, making it ideal for environments where energy management is crucial.
3

Key Features

Rated IP65, the actuator is protected from dust and water, and its wide temperature range of -20°C to 70°C ensures reliable operation in demanding conditions.

ARI-PREMIO Plus 2G 2,2 to 5 kN
Force Ranges: 2.2 to 5 kN
Operating Speeds: 0,25 mm/s to 1 mm/s
Maximum Travel Distances: 50 mm
Supply Voltages (V - Hz): 24 V AC/DC
Motor Types: BLDC Motor (5 kN)
Power Consumption: max. 28 VA (2.2 kN), & max. 30 VA (5 kN)
Enclosure Ratings: IP65
Storage Temperature Ranges: -40°C to 85°C
Ambient Temperature Ranges: -20°C to 70°C
Weight Ranges: 5.4 KG

ARI-PREMIO Plus 2G 12 to 25 kN
12 kN, 15 kN, & 25 kN
0,20 mm/s to 0.79 mm/s
65mm
24 V AC/DC
BLDC Motor
max. 62 VA (12 kN), max. 74 VA (15 kN) & max. 137 (25 kN)
IP65
-40°C to 85°C
-20°C to 70°C
9.5 KG (12 kN & 15 kN), & 11 KG (25 kN)

Actuator Resources

  • Document
DATASHEET

ARI-PREMIO Plus 2G Electric Actuator
  • Document
Operating Instructions

ARI-PREMIO Plus 2G Electric Actuator

Frequently Asked Questions

Electric actuators can be highly energy-efficient, especially when compared to traditional hydraulic or pneumatic systems. They only consume electricity when in operation, and advancements in motor technology, such as brushless DC motors, contribute to increased efficiency.

Yes, there are electric actuators specifically designed for hazardous environments, including those with explosive atmospheres. These actuators adhere to industry-specific standards and certifications, such as ATEX or IECEx, to ensure safety in potentially dangerous settings.

An electric actuator is a device that converts electrical energy into mechanical movement to control the position or operation of a mechanism, typically used in industrial automation and various other applications.

Electric actuators work by receiving an electrical signal, usually from a controller or a computer, and converting it into linear or rotary motion. This is achieved through the use of electric motors, gears, and other mechanical components.

Electric actuators offer precise control, high efficiency, and low maintenance compared to other types of actuators. They are also cleaner and more environmentally friendly as they don't require hydraulic fluids.

There are various types of electric actuators, including linear actuators, rotary actuators, screw jack actuators, and others. Each type is designed for specific applications and motion requirements.

Electric actuators find applications in industries such as manufacturing, aerospace, automotive, robotics, water treatment, and more. They are used wherever precise and automated control of mechanical systems is required.

Yes, many electric actuators are designed to be weatherproof and can withstand harsh environmental conditions. However, it's essential to choose the right actuator with the appropriate protection ratings for outdoor use.

Yes, electric actuators can be easily integrated into various automation systems. They are compatible with programmable logic controllers (PLCs), distributed control systems (DCS), and other control devices.

Factors to consider include load requirements, speed, precision, environmental conditions, duty cycle, and available power supply. Choosing the right actuator depends on the specific needs of the application.

Electric actuators generally have lower maintenance requirements compared to hydraulic or pneumatic actuators. However, it's essential to follow the manufacturer's recommendations for periodic checks and lubrication.

Yes, electric actuators are often used as retrofit solutions to replace older mechanical or hydraulic systems. They offer advantages such as improved control, energy efficiency, and reduced maintenance costs in such applications.
